Blackmagic Design Mini Converter – SDI to Analog 4K

$485.00

Video Convertor – SDI to Analog 4K

Purchase & earn 485 points!
Add to CompareAdded
SKU: MINI-C-SDI-ANALOG-4K Category: Tag:

`Feature-packed Conversion with a Small Footprint

When you need video conversion hardware with a tiny footprint, you can’t go wrong with the Mini Converter SDI to Analog 4K from Blackmagic Design! This tiny but mighty device is ideal for broadcast, post-production, and professional AV applications, and it’s small enough to add to any mobile rig. Just like magic, the Mini Converter lets you to convert Single Link SD/HD/3G/6G-SDI to analog SD/HD component, composite, or S-Video. You can connect professional SDI equipment and output resolutions to SD and HD analog video monitors and other equipment (at resolutions up to Ultra HD 4K 3840 x 2160 and DCI 4K 4096 x 2160). With a straightforward rugged design and simple controls, there’s no better compact conversion solution than the Blackmagic Design Mini Converter from Citymusic!

Blackmagic Design Mini Converter – SDI to Analog 4K Features:

  • Compact SDI to Analog 4K video converter
  • Converts Single Link video signal into analog SD/HD component, composite, or S-Video
  • Great for converting SDI equipment into SD or HD for monitors and other equipment
  • Includes 12V power supply and 4-pack of travel-friendly multinational wall adapters





Type

Video Converter

Video Formats

4K

Video Inputs

2 x BNC (SDI/ALT SDI)

Video Outputs

4 x BNC (SDI/Y/B-Y/R-Y/S-video)

Audio Outputs

2 x 1/4" (L/R/AES/EBU)

USB

1 x Type Mini-B (service)

Form Factor

Portable

OS Requirements - Mac

macOS 10.15 or later

OS Requirements - PC

Windows 10 (64-bit) or later

Power Source

12V DC power supply (included)

Height

0.9"

Width

4.84"

Depth

3.63"

Weight

10.68 oz
